Ultrasonic Bottle Washing Machine

Ultrasonic Bottle Washing Machine

The ultrasonic bottle washing machines are mainly used for rough cleaning of 50 ml, 100 ml, 250 ml and 500 ml IV solution glass bottles. In addition, they can also be used for ultrasonic cleaning of similar bottles.

Request a Quote
Performance Characteristics
  • Due to its compact structure, the ultrasonic bottle washing machine occupies small floor space.
  • The conveyor is placed at the side of the equipment, making maintenance and repair convenient.
  • The bottle washer adopts crawler to carry bottles. The bottles are soaked longer in the ultrasonic water tank and the water pouring time after rinsing is also increased. This ensures bottle cleanness and no residual water left in bottles. In addition, ultrasonic washing avoids dead spot or punctured bottleneck caused by using hairbrush.
  • The equipment will not start up or will automatically shut down if the water level is lower than the minimum standard water level, thus effectively protecting the ultrasonic generator.
  • The ultrasonic bottle washing equipment adopts frequency conversion speed regulation.
  • It features a new simple structure. The glass bottles enter and exit in the same direction.
  • Bottle entering adopts the combination of bottle hook and the guide plate, which makes bottles enter more reliably without bottle collapse or overturn phenomenon.
  • To prevent bottles from being broken or reversed due to long falling distance during exiting process, those bottles are received twice as there is a support to slightly receive bottles first for buffer purpose.
Main Technical Parameters
Model QBX12B QCX20 QCX26 QCX30
Applicable bottle size 50 ml, 100 ml, 250 ml, 500 ml 50 ml, 100 ml, 250 ml
Capacity 80-200 bottle/min 200-300 bottle/min 300-500 bottle/min 300-600 bottle/min
Number of bottles can be entered each time 12 20 26 30
Electric capacity 8 kW 15 kW 18 kW 18 kW
Washing temperature 40-50 ℃
Water consumption Ordinary water: 200 ml/bottle 0.2 MPa
Outer dimension (mm) 4275X2838X1600 3850X3920X1600 3850X4520X1600 3850X4550X1600
Note: In the above table, the capacity is inversely proportional to the bottle size. Hence, the bigger the bottle size, the lower the capacity. The specific details are correct based on the tender documents.
